BERGAMONT HANS-ON
Model : 291045
For everyone who doesn't want more than needed and no less than required: The all-new HANS-ON, developed from scratch, is a super compact bike with uncompromising riding characteristics and a wide range of use. With its short wheelbase of just 105 cm, the compact bike scores as a dynamic commuter as well as a reliable companion in the intermodal split.
Frame20", lite AL-6061 tubing
ForkBGM rigid fork, alloy, 15x100 mm axle
Rear DerailleurShimano RD-R3000
ShiftersShimano SL-R3000, 1x9-speed, rapidfire plus-shifter
CranksetFSA CK-201, 42t
BB-SetSealed cartridge, BSA
ChainKMC X9
CassetteShimano CS-HG201, 11-34t
Brake LeversShimano BL-MT200, hydraulic disc brake
BrakesShimano BR-MT200, hydraulic disc brake
RotorShimano SM-RT10, 160 mm
HandlebarBGM Pro, high-riserbar, backsweep: 15°
H'stemSatori Fastback, with speedlifter
SeatpostSatori Trident, 450 mm
SeatSyncros Capilano Urban
HeadsetAcros, A-Headset, semi-integrated, 1.5", with integrated cable routing
Hub (Front)KT JH-KC5F dynamo hub, 32h, 15x100 mm axle
Hub (Rear)Shimano FH-M3050, centerlock, disc, quick release
SpokesSapim Leader
RimsRyde Andra 40, disc
Front TireSchwalbe Super Moto-X, Greenguard, 62-406Tube: Impac AV20
Rear TireSchwalbe Super Moto-X, Greenguard, 62-406Tube: Impac AV20
LightsFront: B&M Dopp N Plus, 35 Lux, LED, standlightRear: B&M Secuzed Plus, integrated in fender
RackAtran front and rear carrier with AVS click system
PedalsMarwi SP-153, foldable
AccessoriesKickstand: Hebie Elex
Approx weight in KG16,9
Colorshiny mortar grey
FenderCurana Apollo, with stainless stays
Frame sizeone size
GripsBGM Comfort, Ergo, double density, clamp version
Max. System Weight130,0 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
