If you’ve been looking for a fast E-Bike that doesn’t scream E-Bike, the Fastlane 10 is your dream come true. Designed to be almost indiscernible from an analog racing bike, Fastlane 10 hides a TQ HPR40 motor drive unit and 290Wh battery in its svelte figure, leaving you fast under the radar.
The pintsize design (relative to other E-Bikes on the market) is thanks to German company TQ, who use a harmonic gear system to deliver a friendly 40Nm of pedal-assisted power in a hypersmooth, lifelike experience with almost zero drag or motor kickback. On a climb, the power supplied is a natural feeling, like your legs getting a second wind to reach the summit. On the flats, it glides you up to 25kmph before smoothly disengaging with almost no drag.
Holding pace is what Fastlane is all about and trim frame lines and a lightweight 10kg build help to maximize battery life that outpaces heavier, bulkier e-bikes in its class. Mode selection is also discreet via controls on the hoods. We’ve equipped the Fastlane 10 with Shimano Ultegra Di2 electronic 2x gearing, versatile, aerodynamic Syncros Capital 1.0 40 wheels, and Schwalbe PRO ONE tires for speed and reliability wherever you ride.
FrameFastlane Road Disc HMX, Endurance geometry, Syncros Cable Integration System, TQ HPR40, UDH Interface, Range Extender Ready
ForkFastlane Road HMX Flatmount Disc, 27.2mm Eccentric Carbon Steerer
Drive UnitTQ HPR40 Mid Motor drive 40Nm max Torque, EU: 25kmh - US: 28mph
BatteryTQ Internal 290Wh
DisplayTQ Bar-End-Display, Bluetooth, ANT+, Dedicated Smartphone app
ChargerTQ AC 90-264V 2A
Rear DerailleurShimano Ultegra Di2 RD-R815024 Speed Electronic Shift System
Front DerailleurShimano Ultegra Di2 FD-R8150Electronic Shift System
ShiftersShimano Ultegra ST-R8170Dual control 24 Speed Electronic Shift System
CranksetFSA e-Bike Carbon CK-713
ChainringFSA 50x34
ChainShimano CN-M8100-12
CassetteShimano CS-R810111-34
BrakesShimano BR-R8170 Hyd.Disc
RotorShimano RT-CL800 rotor 160/F and 160/R
HandlebarSyncros IC-R100-SLCarbon combo
SeatpostSyncros Duncan 1.0 iL D-shape
SeatSyncros Belcarra V 2.0 NEO Cut Out
HeadsetAcros AIF-1317S
WheelsetSyncros Capital 1.0 40 Disc, Front 12x100mmTA, Rear 12x142mmTASyncros SL Axle
Spokes24 Front, 24 Rear
Front TireSchwalbe PRO ONE Evo, 700x34C
Rear TireSchwalbe PRO ONE Evo, 700x34C
LightsSyncros Campbell iL rear
AccessoriesCoupe Cage 1.0 bottle cageSyncros iS Drop Bar Tool 2
Approx weight in KG10.6
Approx weight in LBS23.37
Max. System Weight120kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
