Claud Butler Alpina 1.0 Mountain Bike
The Claud Butler Alpina range has been completely overhauled for 2024, with two models, a new frame, modern trail riding geometry and the latest in Shimano CUES – our vision for the Alpina was to create a bike that thrives exploring UK trails.
The Claud Butler Alpina 1.0 is our introductory model to the all-new Alpina range – designed to help you cover anything from the many miles of canal towpath right through to the thrill of off-road trail riding.
Using Shimano’s latest CUES series drivetrain components, the 2x9 drivetrain offers all the gears you could need with a 22/36t chainset and 11-36t cassette. We have also stayed with Shimano for the brakes, using their ever-reliable MT200 hydraulic disc brakes that offer consistent and reliable stopping power.
The Alpina was always about developing a mountain bike that could handle the demands of UK trail centres and off-piste wild tracks, and central to that is modern-thinking frame geometry, specifically built around a 100mm fork and 29in wheels. Longer top tubes and slacker head angles combined with super short 45mm stems and ultra-wide 750mm handlebars result in a confidence inspiring ride that feels controlled while you enjoy the thrill of the trail. Adding to this, we’ve used 29x2.25” WTB Ranger tyres that are known for their fast-rolling, good puncture resistance and good grip across a range of trail conditions.
All in, the Alpina 1.0 is a diverse bike suited to a variety of riding environments and is ready to tackle whatever you can throw at it.
Frame | Claud Butler 6061 Hydro-Formed T6 Alloy, Multi Butted, Internal Cable Routing |
---|---|
Fork | SR Suntour XCM-HLO, Alloy Crown, 100mm Travel Lockout, Post Mount |
Headset | FSA, 1.1/8” Cartridge A-headset, Semi-Integrated |
Handlebar | Low Rise Alloy Handlebar, 750mm Wide, 31.8mm Clamp, 12.5mm Rise, 6 Degree Backsweep |
Stem | Alloy, 45mm Length. 31.8 Clamp |
Grips | Lock-on Grip, Black |
Gear Shifters | Shimano CUES Rapidfire Plus SL-U4000-9R |
Rear Derailleur | Shimano CUES RD-U3020, Shadow Plus design |
Front Derailleur | Shimano CUES FD-U4000-L, low clamp |
Freewheel | Shimano CUES CS-LG300-9, 11-36t |
Chainwheel | Shimano CUES FC-U4000-2, 22-36t, 170mm |
Bottom Bracket | BSA Threaded Cartridge |
Brakes | Shimano Hydraulic Disc Brakes BR-MT200 160mm Center Lock Rotors |
Brake Levers | Shimano Lever |
Pedals | 9/16" Alloy MTB |
Front Hub | Shimano 32H Alloy Quick Release |
Rear Hub | Shimano 32H Alloy Quick Release |
Rims | 29" Alloy, Double Wall, 32H |
Spokes | 14G, Black |
Tyres | WTB Ranger, 29 x 2.25" |
Saddle | Claud Butler MTB |
Seat Post | Alloy micro adjustable, 30.9mm x 350mm |
