| FRAME MATERIAL |
Kona 6061 Aluminum Butted 153mm Travel |
| SIZES |
S, M, L, XL |
|
|
| Rear Shock |
RockShox Deluxe Select Plus Trunnion
|
| Fork |
RockShox Yari RC Motion Control DebonAir 160mm Tapered 110mm Spacing |
| Crankarms |
Shimano Deore |
| Chainrings |
30t |
| B/B |
Shimano Deore PF92 |
| Pedals |
n/a |
| Chain |
KMC X11 |
| Freewheel |
Sunrace 11-51t 11spd |
| Chainguide |
n/a |
| F/D |
n/a |
| R/D |
Shimano Deore 11spd
|
| Shifters |
Shimano Deore 11spd
|
| Brake Calipers |
Shimano Deore
|
| Front Brake Rotor |
Shimano RT64 203mm (centerlock)
|
| Rear Brake Rotor |
Shimano RT64 180mm (centerlock)
|
| Brake Levers |
Shimano Deore
|
| Headset |
FSA No.57B |
| Handlebar |
Kona XC/BC 35
|
| Stem |
Kona XC/BC 35 |
| Seatpost |
TranzX Dropper +RAD Internal w/ Shimano Lever 31.6mm |
| Seat Clamp |
Kona Clamp |
| Grips |
Kona Key Grip |
| Saddle |
Kona Trail
|
| Front Hub |
Shimano 110x15mm |
| Rear Hub |
Shimano 148x12mm |
| Spokes |
Stainless Black 14g
|
| Rims |
WTB ST i30 TCS 2.0 |
| Front Tire |
Maxxis Assegai EXO TR DUAL 27.5x2.5" WT |
| Rear Tire |
Maxxis Minion DHR II EXO TR DUAL 27.5x2.4" WT
|
| Paint Color |
Gloss Mocha w/ Black & Orange Decals
|
| Extras |
n/a |
