Fox Rhythm 34 Float with eMTB+ 140mm fork with DPS Performance inline rear shockShimano Deore 1x 12spd drivetrain with 10-51t cassette
Shimano Deore 4-piston brakes
TranzX dropper post
Maxxis Minion DHF/DHR II EXO+ tires
65° HTA with 140mm fork
Satellite power button
Reach matches Process 134
Shimano E7000 motor w/ internal 504Wh battery
76° STA
435mm CSL
Clearance for 29x2.5” tires
Frame Material - Kona 6061 Aluminium Butted 130mm Travel
Rear Shock - Fox Performance Float Trunnion
Fork - Fox Rhythm 34 Float 140mm Tapered 110 Spacing
Crankarms - Shimano E8000
Chainrings - 36t
Chain - Shimano Deore
Cassette - Shimano Deore 10-51t 12spd
R/D - Shimano Deore
Shifters - Shimano Deore
Brake Calipers - Shimano Deore
Front Brake Rotor - Shimano RT66 203mm
Rear Brake Rotor - Shimano RT66 180mm
Brake Levers - Shimano Deore
Headset - FSA No.57E
Handlebar - Kona XC/BC 35
Stem - Kona XC/BC 35
Seatpost - TranzX Dropper Internal 31.6mm
Seat Clamp - Kona Clamp
Grips - Kona Key Grip
Saddle - WTB Volt
Front Hub - Formula 110x15mm
Rear Hub - Formula 148x12mm
Spokes - Stainless Black 14g
Rims - WTB KOM Trail i35 TCS 2.0
Front Tire - Maxxis Minion DHF EXO+ TR 3C 29x2.5" WT
Rear Tire - Maxxis Minion DHR II EXO+ TR 3C 29x2.4" WT
DriveUnit - Shimano E7000 25KPH
Battery - Shimano 504Wh
Display - Shimano SC-E7000 Display
Charger - Shimano STEPS 2A
