427714
Key features
- 125–135 cm / 49–53" bodyheight
- 24" wheels with high-grip tires
- Powerful disc brakes
- Suspension fork for extra fun & control
- 8-speed drivetrain to master the up's & down's
- Kids-specific components
- Kickstand included
- Built to rock the local trails.
| Frame |
KIDS24 disc, Alloy 6061, custom tubing, semi int. CBR, BB68, SCOTT dropout, PM
|
| Fork |
SR Suntour XCT JR, 24'', softer spring setup
|
| Travel |
50mm
|
| Headset |
Feimin, 48/28.6/44/30, semi int.
|
| Rear Derailleur |
Shimano Tourney RD-TX800, 8 Speed
|
| Shifters |
Shimano RevoShift SL-RV400 with Display
|
| Brake Levers |
Tektro KIDS specific, adjustable reach
|
| Brakes |
Tektro hydraulic disc brake
|
| Crankset |
Prowheel, Alloy Crank, 30T, w/CG PVG double cover
|
| Front Disc Rotor |
160mm
|
| Rear Disc Rotor |
160mm
|
| BB-Set |
Feimin, BB68, cartridge, square taper
|
| Handlebar |
Leadtec Kids' riser bar alloy D:19, 20mm rise, 25.4mm clamp
|
| H'stem |
Leadtec, Alloy, +10°, 25.4 clamp
|
| Pedals |
Kids Pedal medium, w/Reflector
|
| Seat |
Syncros KIDS III Incl. Seatpost 27.2mm, 300mm
|
| Front Hub |
Formula DC-19, 24H, disc 6 bolt, 5x100mm, QR/allen key
|
| Rear Hub |
Formula DC-25, 24H, disc 6 bolt, 8s, 5x135mm, QR/allen key
|
| Chain |
KMC Z8
|
| Cassette |
Sunrace CSM55 8-Speed, 11-34T
|
| Front Rim |
Alloy, 24H, 507-21, A/V, for disc brake
|
| Rear Rim |
Alloy, 24H, 507-21, A/V, for disc brake
|
| Extras |
Kickstand
|
| Accessories |
Syncros Stem Protector
|
| Approx weight in KG |
10.8 w/o Pedals and Kickstand
|
| Approx weight in LBS |
23.81 w/o Pedals and Kickstand
|
| Grips |
Syncros Kids' Grips ID19, OD 25.5 , 100/80
|
| Front Tire |
Kenda Karma 2 24 x 2.2, 60TPI
|
| Rear Tire |
Kenda Karma 2 24 x 2.2, 60TPI
|
| Max. System Weight |
70kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
|
